Smoke tester / Smoke machine Turbo/Intake (43060-TB) Mastercool

Mastercool Turbo/Intake Diagnostic Smoke Machine (43060-TB)

Mastercool 43060-TB is a diagnostic smoke machine for turbo, intake and exhaust systems , developed for professional leak detection in vehicles. The machine is suitable for testing turbo, intake, exhaust, vacuum hoses and vacuum components, manifolds , as well as leaks in the passenger compartment, windows, sunroofs and light fixtures.
Not intended for EVAP testing.

The unit provides high flexibility by being able to use a built-in internal compressor , workshop air or inert gas to inject smoke into the system, and is well suited for both workshop and mobile missions.

Precise leak detection for turbo and intake

Designed for applications requiring higher test pressures than EVAP , the 43060-TB features adjustable working pressures up to 28 PSI . It delivers fast and consistent smoke production and is equipped with an easy-to-read pressure gauge (0–30 PSI) for controlled and safe testing.

Robust construction, reliable performance and complete accessories make this an effective tool for professional technicians working on turbo and intake systems.

Features

• Compact and robust construction for long service life

• More options for smoke introduction:

  • Built-in internal compressor

  • Workshop air

  • Inert gas

• Fast smoke production

• Built-in safety pressure relief valve

• Adjustable working pressure from 0 to 28 PSI

• Large and easy-to-read pressure gauge: 0–30 PSI

• Non-toxic and non-corrosive fumes

• 10' (3 m) 12 V power cables with solid clamps

• Heavy duty 10' (3 m) smoke exhaust hose

• Velcro for easy storage of hose and cable

Package contents

• Turbo/Intake diagnostic smoke machine

• Inflatable suction bladder

• Complete set of block plugs

• Exhaust/diagnostic cone

• Powerful battery-powered smoke lantern

• 8 oz (about 240 ml) smoking liquid

• 10' power cord for connection to vehicle battery

Technical specifications

• Voltage: 12V DC

• Inlet pressure: Max 100 psi (7 bar)

• Output pressure:

  • Internal pump: 22 psi (150 kPa) max

  • External pressure source: max 28 psi (190 kPa)

• Safety overpressure: 120 psi (±5 psi)

• Oil fill indicator: 100 ml (±10 ml)

• Flow Meter: 0–0.040 in (0–1.0 mm)

• Power consumption: Max 6.5 A

• Operating temperature: −17 °C to +60 °C

• Operating humidity: No restrictions

• Operating altitude: No restrictions

• Smoke exhaust hose: 10 ft (3 m)

• Power cable: 10 ft (3 m)

• Pressure supply: Air / inert gas / internal pump

• Dimensions: 300 × 205 × 280 mm

• Weight:

  • Net: 5.2 kg

  • Shipping weight: 10 kg

Available accessories

• 43060-DW-ST – Diffuser unit, short

• 43060-OL – 8 oz bottle of smoke liquid
